7NJ9-S 90 ° NPT FEMALE / JIC FEMALE 74 ° Größentabelle wie folgt:
PAR T NEIN | GEFAHR D | ABMESSUNG S | ||||
E | F | EIN | B | S 1 | S 2 | |
7NJ9-04 S | Z1 / 4 "X1 8 | 7/16 "X2 0 | 22. 5 | 9 | 1 9 | 1 5 |
7NJ9-04-06 S | Z1 / 4 "X1 8 | 9/16 "X1 8 | 22. 5 | 10. 5 | 1 9 | 1 9 |
7NJ9-06-04 S | Z3 / 8 "X1 8 | 7/16 "X2 0 | 2 7 | 9 | 2 4 | 1 5 |
7NJ9-06 S | Z3 / 8 "X1 8 | 9/16 "X1 8 | 2 7 | 10. 5 | 2 4 | 1 9 |
7NJ9-06-08 S | Z3 / 8 "X1 8 | 3/4 "X1 6 | 2 7 | 10. 5 | 2 4 | 2 4 |
7NJ9-08-06 S | Z1 / 2 "X1 4 | 9/16 "X1 8 | 31. 2 | 10. 5 | 3 0 | 1 9 |
7NJ9-08 S | Z1 / 2 "X1 4 | 3/4 "X1 6 | 31. 2 | 10. 5 | 3 0 | 2 4 |
7NJ9-08-10 S | Z1 / 2 "X1 4 | 7/8 "X1 4 | 31. 2 | 1 2 | 3 0 | 2 7 |
7NJ9-12 S | Z3 / 4 "X1 4 | 1,1 / 16 "X1 2 | 34. 5 | 1 5 | 3 3 | 3 2 |
7NJ9-12-16 S | Z3 / 4 "X1 4 | 1,5 / 16 "X1 2 | 34. 5 | 1 6 | 3 3 | 4 1 |
7NJ9-16-12 S | Z1 X11. 5 | 1,1 / 16 "X1 2 | 4 3 | 1 5 | 4 1 | 3 2 |
7NJ9-16 S | Z1 X11. 5 | 1,5 / 16 "X1 2 | 4 3 | 1 6 | 4 1 | 4 1 |
7NJ9-20 S | Z1.1 / 4 "X11. 5 | 1,5 / 8 "X1 2 | 43. 2 | 1 7 | 5 0 | 5 0 |
7NJ9-24 S | Z1.1 / 2 "X11. 5 | 1,7 / 8 "X1 2 | 52. 8 | 2 0 | 6 3 | 6 0 |
